Description
NEW The plastic tubes for this check valve kit each have a ball inside. The one with the tube on the side is 6″ long. One end has a 5/8″ outside diameter that increases to a 7/8″ outside diameter with a 1/2″ inside diameter. The other end has a 1″ outside diameter with a 13/16″ inside diameter. The side tube is 1 7/16″ long with a 1″ outside diameter and a 13/16″ inside diameter. The different plastic tube is 5 1/4″ long with a 1 11/16″ outside diameter through the middle and a 1 1/8″ outside diameter with a 7/8″ inside diameter on each end. The small rubber gasket is 5/32″ high with a 13/16″ outside diameter for the bottom and a 9/16″ outside diameter for the top and the inside diameter is 7/16″. The larger rubber gasket is 1/2″ high with a 1 13/16″ outside diameter and a 1 5/8″ inside diameter on one end. The other end has a 1 3/16″ outside diameter with a 1″ inside diameter.
This kit has a part number of 2160116 but the manufacturer is unknown.
Additional information
| Weight | .38 lbs |
|---|---|
| Dimensions | 7 × 5 × 2 in |
