Valve, Drain for Distribution Tank, Auto, 1 15/16″W, 2 1/8″H

Name: Valve, Drain for Distribution Tank, Auto, 1 15/16"W, 2 1/8"H
SKU: SDL-000-018N 09SS07
Price: 25 USD
Availability: InStock

$25.00

NEW Valve, Drain, Auto for Distribution Tank, 1 15/16″ W, 2 1/8″ H

1 in stock

SKU: SDL-000-018N 09SS07Categories: Clean In Place

Description

NEW This automatic drain valve for a distribution tank is composed of a plastic body, rubber valve seat, dense plastic ball, and metal cotter pin. The total body height is 2 1/8″. The threaded end outside diameter is 1 10/16″, inside diameter is 1 5/16″, width is 1 10/16″ and the length is 3/4″. The smooth end outside diameter is 1 15/16″, inside diameter is 1 11/16″, width is 1 15/16″, and the length is 1 3/16″. The upper seat of the rubber valve seat is 1 10/16″ wide, the outside diameter measures the same. The lower end of the seat has an outside diameter of 1 3/16″ and an inside diameter of 10/16″. The ball is 14/16″ in diameter. The cotter pin is 3″ long.

The manufacturer is DeLaval, the product number is 8301379-80.

Additional information

Weight	.19 lbs
Dimensions	3 × 3.5 × 3 in
Brand	DeLaval
